Product Description
Middleby Marshall PS Series conveyor ovens bake both faster and at a lower temperature than other ovens. Vertical columns of hot air move heat aerodynamically instead of using high temperatures.
The streams of hot air remove the boundary layers of cool heavy air which tend to insulate the product. All Middleby ovens are designed to cook a multitude of products including pizza, seafood, sandwiches, bagels, ethnic foods and more.
Impingement PLUS! low oven profile and dual air return
Patented EMS Energy Management System* reduces gas consumption and increases cooking efficiency
40-1/2” (1029mm) long cooking chamber
32” (813mm) wide, 76-1/2” (1943mm) long conveyor belt
Patented “Jet Sweep” impingement process that delivers constant heat to the chamber
Stackable up to three units high
Microprocessor-controlled bake time/conveyor speed
Customer-specific adjustable jet fingers that allow control of heating delivery
Stainless steel front, sides, top and interior
Front-loading window with cool handle
Reversible conveyor direction
General Information
The PS540 conveyor oven is ideally suited for medium-duty
restaurant needs. The oven can cook a wide variety of food
products, including pizza, seafood and bagels.
Standard Features
• Impingement PLUS! low oven profile and dual air
return
• Patented EMS Energy Management System* reduces
gas consumption and increases cooking efficiency
• 40-1/2” (1029mm) long cooking chamber
• 32” (813mm) wide, 76-1/2” (1943mm) long conveyor
belt
• Patented “Jet Sweep” impingement process that delivers
constant heat to the chamber
• Stackable up to three units high
• Microprocessor-controlled bake time/conveyor speed
• Customer-specific adjustable jet fingers that allow control
of heating delivery
• Stainless steel front, sides, top and interior
• Front-loading window with cool handle
• Reversible conveyor direction
Optional Features
• Split belt - two 15” (381mm) belts with individually
adjustable speed settings
• High speed conveyor (Range of 1:00 - 10:00)
• Adjustable legs (replace casters)
• Stainless steel lower shelf on double and triple oven
Conserves Energy
Unit incorporates a patented Energy Management System - EMS.
Middleby ovens provide very efficient heat transfer to product.
Energy is conserved as air is recycled from heater to product,
with minimum loss. Oven is cool to the touch.
Cleanability
PS540 Ovens are designed for easy cleaning. Removable parts
include: crumb pans, end panels, air fingers, exit tray, and a
removable conveyor belt assembly.
Easily Services
Control compartment is designed for quick and easy access.
Warranty
All PS540 models have a one year parts and labor warranty.
Ventilation
Use of a ventilation hood is required.
*Photos show ovens equipped with casters. Some installation codes require the
use of adjustable feet instead of casters.
